CNC Heavy Duty Lathe STANKOIMPORT-KRAMATORSK 1A 660H-6000 CN

Category	CNC Lathes and Turning Centers STANKOIMPORT-KRAMATORSK ›
Manufacturer	STANKOIMPORT-KRAMATORSK ›

ARCHIVED AD

CNC Heavy Duty Lathe STANKOIMPORT-KRAMATORSK 1A 660H-6000 CN was manufactured by the machine manufacturer STANKOIMPORT-KRAMATORSK. Machine STANKOIMPORT-KRAMATORSK 1A 660H-6000 CN was built in 1989 year.

General data
Location	Italy
region	Brescia
Year of manufacture	1989
Warranty	Without warranty

Technical parameters
Maximum length of the turning	6000 mm
Turning diameter over bed (max)	1750 mm
Turning diameter over cross slide (max)	1250 mm
Maximum power of the main spindle	110 kW
Minimum rotary speed of the main spindle	1.2 1/min
Maximum rotary speed of the main spindle	310 1/min
Workpiece weight between centers (max)	25000 kg
Tailstock quill diameter	300 mm
Maximum travel length of the tailstock quill	260 mm
Weight of the lathe	48 t
