Technical parameters |
|---|
| Maximum turning length (Z-axis) |
519.9 mm |
| Turning diameter over bed (max) |
529.8 mm |
| Turning diameter over cross slide (max) |
419.9 mm |
| Maximum travel length in the X-axis |
259.8 mm |
| Maximum feed rate in X-axis |
25 m/min |
| Maximum feed rate in Z-axis |
20 m/min |
| Maximum power of the main spindle |
22.4 kW |
| Diameter of the spindle bore |
80 mm |
| Minimum rotary speed of the main spindle |
45 1/min |
| Maximum rotary speed of the main spindle |
4500 1/min |
| Total number of tools in the turret |
12 pcs |
| Number of driven tools in the turret |
12 pcs |
| Length of the lathe |
2387.6 mm |
| Width of the lathe |
1828.8 mm |
| Height of the lathe |
2184.4 mm |
| Weight of the lathe |
4.3 t |
