Technical parameters |
|---|
| Length of the working table |
1099.8 mm |
| Width of the working table |
490.2 mm |
| Maximum table load (evenly distributed) |
798.3 kg |
| Power of the spindle drive |
11.2 kW |
| Number of tools in the magazine |
24 pcs |
| Minimum rotary speed of the vertical spindle |
100 1/min |
| Maximum rotary speed of the vertical spindle |
8000 1/min |
| Minimum distance of the spindle from the table |
139.7 mm |
| Maximum distance of the spindle from the table |
701 mm |
| Travel length X-axis (mechanical feed) |
1016 mm |
| Travel length Y-axis (mechanical feed) |
508 mm |
| Travel length Z-axis (mechanical feed) |
558.8 mm |
| Machine weight |
6.5 t |
