Technical parameters |
|---|
| Length of the working table |
2000 mm |
| Width of the working table |
1249.9 mm |
| Maximum table load (evenly distributed) |
9979 kg |
| Number of CNC controlled axles |
5 pcs |
| Maximum rotary speed of the vertical spindle |
24000 1/min |
| Maximum distance of the spindle from the table |
909.8 mm |
| Travel length X-axis (mechanical feed) |
1650 mm |
| Travel length Y-axis (mechanical feed) |
749.8 mm |
| Travel length Z-axis (mechanical feed) |
849.9 mm |
| Maximum feed rate in X-axis |
500 mm/s |
| Maximum feed rate in Y-axis |
500 mm/s |
| Maximum feed rate in Z-axis |
500 mm/s |
| Machine length |
4699 mm |
| Machine width |
3886.2 mm |
| Machine weight |
18.3 t |
